AC Micro Milli Voltmeter

AC Micro Milli Voltmeter
AC Micro Milli Voltmeter
Product Code : 401
Product Description

Since our inception in the year 1965, we have established ourselves as a leading manufacturer and supplier of AC Micro Milli Voltmeter. These voltmeters are manufactured by our expert personnel team using the superior grade materials and components which we source from the reliable vendors. These instruments are used to measure the AC Voltage of different equipments. Our equality inspectors check the AC Micro Milli Voltmeter on durability and functionality parameters before offering the clients at the affordable prices.

Features:

  • Easy operation

  • Sturdily constructed

  • Accurate calibration

Further Details:

Systronics AC Mcro/Milli Volt Meter 401 is a solid state precision instrument, measurng AC Voltages from 10µV to 500 V r.m.s. over a frequency range of 1Hz to 3MHz. Designed for easy operation, the instrument gives direct reading of voltage or dB on diital display.

The unit uses a stable, high gain AC amplifier, which delivers essentially, a hum free, low noise micro phony signal output. Operated on mains, this test instrument is sturdily constructed and is enclosed in an elegan metallic cabinet with a pair of rugged, plastic moulded, dual position stands.


Technical Specifications:

Range
Voltage: 2 mV to 2000 V Full Scale in
7 Decadc Range, (Max. 500 V)
dB: 60 dB to + 60 dB in steps of 20 dB
(Reference: 0 dB corresponds to 1 mW across 600Ω)

Measuring Rane
Voltage: 10 µV to 500 V

dB: 95 dB to + 56 dB

Measurement Accuracy
(AT 1KHz)
Voltage Scale: +- 1% of Full Sclae +- 1 diit
dB Sclae: +- 0.5 dB

Frequency Response
(At 0.0 dB; 0.775 V)
+- 0.5 dB from 4 Hz to 1 MHz &
+- 3.0 dB from 1 Hz to 3 MHz

Display
Seven segment LED; 3.1/2 Digit

Input mpedance
For 2 mV & 20 mV Ranges: 5 MΩ // 50 pF (Approx.)
Above 20 mV ranges: 5 MΩ // 20 pF (Approx.)

Input Noise
For 2 mV Range: 5 µV + 5 Least Counts
20 mV & Above: 5 Least Counts

Amplifier
The output is phase inverted, undistorted replica of input in
mV correspondin to displayed figure irrespective of range
with maximum 200 mV at full scale

Maximum Safe Input
For 2 mV & 20 mV Range: 250 V DC + 100 V AC
upto 20 KHz

Above 20 mV Range: 750 V peak AC + DC

Power Supply
230 V, 50 Hz +- 10%

Dimension
65 x 215 x 210 mm

Weight
@ 1.75 Kg.
